Cornet ED88TPlus2 Tri-Mode
Cell towers | Smart meters | WiFi signal strength meter | Microwave ovens | Power lines | Transformers | Home appliances

Cornet ED88TPlus2---- $229.⁹⁰ $219.⁹⁰ (Worldwide Free Shipping)
A Tri-mode meter for up to 8GHz/10KHz

(0.1-8GHz) RF/LF Electrosmog field strength power meter with build-in Gauss meter and E-Field function (Tri mode) with sound output and USB PC connection

  Download manual

Download USB Driver

Download PC software

  Applications:

• Electromagnetic field strength measurement. both low frequency and high frequency.
• Mobile phone base station radiation power Density safety measurement.
• Telecommunications(CW,TDMA,GSM,DECT).
• RF safety measurement.
• RF power measurement for transmitters.
• Wireless LAN (Wi-Fi) detection, installations.
• Smart meters
• Spy camera, wireless bug finder.
• Cellular/cordless phone radiation safety level.
• Microwave oven leakage detection.
• Electric and magnetic field measurement.
• E-field mode: measured ELF electric field strength is shown on the digital LCD display with V/m.
• Personal living environment EMF safety.
• Data logging via USB to PC connection software.

Specs:

• Tri operation mode: RF power meter mode, LF Gauss meter mode and LF E-Field mode.
• RF Frequecy range: 100MHz to 8GHz (RF meter), (-60dBm to +5dBm),(0.5uw/m2 to 1.8w/m2), (14mv/m to 26.2v/m).
• Shows the broadcast frequency (100MHz - 2.7GHz) range.
• LF1: 50Hz to 10KHz (0.1uT to 60uT)/(1mG to 600mG).
• LF2: 50Hz to 1KHz (0.01uT to 1uT)/(0.1mG to 10mG).
• E-field bandwidth of 50Hz-50KHz with sensitivity of 10v/m to 1000v/m.
• Peak power density measurement 1.5uW/m2 to 0.58W/m2.
• LCD Backlight: 15 seconds auto-off and manual on/off control.
• LCD Histogram and bar display to display power density level.
• Sampling rate: 10,000/sec. Display update rate: 2/sec.
• Error rate: +/- 3.5dBm, LF: 20%, E-field: 25%.
• Analog RF(AM,FM) and Digital burst RF(GSM,TDMA,CDMA,DECT, ZigBee, Bluetooth, UWB, WiFi, WiMAX 2.4GHz, 3.6GHz, 5.8GHz).
• Max and Hold function, mW/m², V/m, dBm, mG, uT.
• Average, Sound output, audio Alarm function. Calibration correction.
• Earphone port.
• Volume control.
• USB connection for data communiation and power supply.
• Audio Sound ON/OFF control, programmable Alarm
  triggering level.
• Accurate, easy to use device, excellent for personal Electrosmog exposure evaluation for living environment, such as close by Mobile phone base station.
• Build-in Sensing Antenna.
• Small, compact handheld design, 69mmX110mm.
• Battery operated (9V DC)
• Constant power option via USB.
